The MRCOOL Universal High-ESP 54,000 BTU Air Handler represents an engineering breakthrough for demanding commercial and large residential installations where conventional air handling equipment consistently underperforms. This robust 4-5 ton (54,000 BTU) system delivers exceptional airflow against significant static pressure – precisely the solution needed for manufactured structures, complex ductwork configurations, and other high-resistance applications that overwhelm standard equipment.
What truly distinguishes the MDUI18048060E is its extraordinary static pressure capability of 250Pa – substantially higher than conventional air handlers. This exceptional specification enables the system to overcome significant airflow restrictions in:
The system's powerful 1HP DC motor drives an impressive 1,600 CFM airflow capacity – 60% more than standard 3-ton units – while maintaining precise control through 8 discrete speed settings. This combination of raw power and refined control allows the system to adapt to varying conditions while maintaining optimal airflow in applications where conventional equipment struggles or fails completely.
Despite its industrial-grade performance capabilities, the Universal High-ESP Air Handler achieves remarkable efficiency ratings of up to 18 SEER, 10.5 EER, and 10 HSPF when properly matched with compatible outdoor units. This efficiency stems from sophisticated DC motor technology that:
The specialized fan blade design works in concert with the advanced motor to generate substantial airflow while maintaining a reasonable 51 dBA noise level – comparable to a modern dishwasher and remarkably quiet for a system with this capacity.
The MDUI18048060E offers exceptional installation flexibility with multi-position capability for upflow or horizontal (left/right) mounting. This adaptability proves invaluable when working within the unique structural constraints of manufactured buildings, retrofit applications, and commercial installations.
Despite its substantial capacity, the unit maintains a manageable footprint (21-1/4"W x 24-3/4"D x 57"H), striking an optimal balance between space efficiency and performance. This dimensional efficiency allows installation in restrictive spaces where larger conventional units simply won't fit.
Unlike proprietary systems that restrict equipment combinations, the Universal High-ESP Air Handler works seamlessly with compatible third-party condensers, offering complete design flexibility. This versatility extends to connection methods, providing three distinct options:
This connection flexibility proves particularly valuable in manufactured housing and remote installations where specialized HVAC tools may be impractical or unavailable.
The Universal High-ESP Air Handler incorporates numerous practical features addressing the specific challenges of high-capacity, high-pressure installations:
The MDUI18048060E excels in precisely the applications where standard air handlers consistently disappoint:
With its exceptional 10-year registered limited warranty and certifications from ETL, Energy Star, and AHRI, the Universal High-ESP Air Handler delivers the reliability and performance assurance essential for these demanding commercial and large residential applications.
The MRCOOL Universal High-ESP 54,000 BTU Air Handler represents specialized technology for applications where conventional equipment has repeatedly proven inadequate. By delivering exceptional performance in the most challenging high-static pressure installations, this advanced system ensures comfort, efficiency, and reliability in environments where compromise was previously unavoidable.
For contractors and property owners who have struggled with inadequate airflow, excessive noise, and premature equipment failure in high-resistance applications, the MDUI18048060E offers a purpose-built solution that addresses these challenges through thoughtful engineering and robust construction – delivering the performance these specialized applications demand.
Key Features
PRODUCT SPECIFICATIONS:
| Product Dimensions | 21-1/4"W x 24-3/4"D x 57"H |
| Product Weight | 203 lbs |
| SEER | Up to 18 |
| EER | 10.5 |
| HSPF | 10 |
| CFM | 1600 |
| Tonnage | 4-5 Ton |
| Cooling Capacity | 54000 BTU |
| Heating Capacity | 54000 BTU |
| Electrical Requirements | Requires a minimum of 208V-230V/60HZ/8A-15A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 15 A |
| Min Circuit Ampacity | 8 A |
| Color | Gray |
| Refrigerant Type | R-410A |
| Decibel Rating | 51 dBA |
| Number of Speeds | 8 Speed |
| lnverter | DC |
| Min Ambient Cool | -5F - 129.2F |
| Min Ambient Heat | -22 F - 75.2F |
| Lineset Included | No |
| Liquid Line Size | 3/8 in |
| Suction Line Size | 3/4 in |
| Blower Motor HP | 1 |
| Filter Type | Washable |
| Filter Size | 20-11/16 X 20-5/16 X 5/8 |
| Auxiliary Heater Available | Yes |
| Auxiliary Heater Sizes | 10KW / 15 KW / 20 KW |
| Overload Protection | Yes |
| Certifications | ETL Energy Star AHRI |
| Warranty | 10 Year Registered Limited Warranty |
| Proposition 65 Warning | Yes |
